V Cut PCB Depaneling Machine With Two Linear Blades Lower Stress
Features:
Pneumatic driven, electric hybrid design, double straight knife cutting, sutiable for dividing precision SMD sheet, aluminum circuit board.
Suitable for all thickness PCB, cutting board stroke is less than 2mm, no operational safety concerns.
Reduce the internal stress generated when cutting the board to below 180μST to avoid tin cracking and prevent damage to precision parts.
Cut the edge of the V groove and the width of the part is 0.3mm, the height is 50mm.
Blades can be re-sharpened
Cutting stress is less than 500 uE.
Specification:
| Model | SMTPD2 |
| Machine Dimension | 720x300x440mm / 520x300x440mm / 500x300x440mm |
| Max Cutting Length | 330mm / 200mm / 130mm |
| PCB Material | FR4, MCPCB, CEM, Copper Boards |
| Air Pressure | 0.4-0.7MPa |
| PCB Thickness | 0.3-3.5mm |
| Power | 110/220V |
| Machine Weight | 130kgs / 100kgs / 80kgs |
